MTSNR4030
MTSNR4030 Series - SMD Power Inductors
| Part Number | Inductance L(uH) | DCR (Ω) ± 30% | Isat (A) | Irms (A) |
|---|---|---|---|---|
| MTSNR40302R2 | 2.2±30% | 0.04 | 4.9 | 2.5 |
| MTSNR40303R3 | 3.3±20% | 0.06 | 3.3 | 2.2 |
| MTSNR40304R7 | 4.7±20% | 0.078 | 2.9 | 1.7 |
| MTSNR40305R6 | 5.6±20% | 0.09 | 2.6 | 1.65 |
| MTSNR40306R8 | 6.8±20% | 0.11 | 2.45 | 1.6 |
| MTSNR40308R2 | 8.2±20% | 0.13 | 2.1 | 1.5 |
| MTSNR4030100 | 10±20% | 0.15 | 1.95 | 1.45 |
| MTSNR4030150 | 15±20% | 0.23 | 1.65 | 1.1 |
| MTSNR4030220 | 22±20% | 0.38 | 1.3 | 1 |
| MTSNR4030330 | 33±20% | 0.5 | 1.1 | 0.8 |
| MTSNR4030470 | 47±20% | 0.65 | 0.95 | 0.7 |
| MTSNR4030560 | 56±20% | 0.9 | 0.85 | 0.65 |
| MTSNR4030680 | 68±20% | 0.95 | 0.75 | 0.52 |
| MTSNR4030820 | 82±20% | 1.05 | 0.66 | 0.47 |
| MTSNR4030101 | 100±20% | 1.15 | 0.6 | 0.45 |
